Mold colonies can be detected and counted rapidly and full automatically !

Mold colonies are detected and counted rapidly and full automatically !

Fully automated rapid mold detection and enumeration ! (Quantitative Analysis)

MicroBio µ3D trade mark

automated rapid mold detection, Microbio μ3D   rapid automated microbial detection system, MicroBio µ3D AutoScanner

Set PDA plates and start a test.

(MicroBio PDA performs well.)



Colony count of mold becomes difficult after prolonged incubation due to the growth of hyphae, causing overlapping each other. When MicroBio µ3D is used for mold detection, colony count can be performed automatically because it monitors the growth of mold from microscopic stage.


Aspergillus brasiliensis Detection

The example below shows how three different agar media detect Aspergillus brasiliensis when MicroBio µ3D is used. PDA, GPLP and Sabouraud agar media were used for detection. The 0.1ml of Aspergillus sample was spread on each plate. Plates were incubated at 28 ℃ for 48h, but the detection was completed for every plate at 35h.

Test System

MicroBio µ3D AutoScanner

Species strain

Aspergillus brasiliensis(NBRC9455)

Sample

0.1ml spread plate



Agar Media

Potato Dextrose Agar (PDA) Media,
Glucose Peptone Agar with Lecithin & Polysorbate 80 (GPLP) Media,
Sabouraud Dextrose Agar (SDA) Media

Incubation

28ºC, 48h

Remarks

Detection and colony count are completed within about 35h.



Potato Dextrose Agar (PDA) Media

Count

Count Graph

Count Marker

92

Aspergillus on PDA





Glucose Peptone Agar with Lecithin & Polysorbate 80 (GPLP) Media

Cout

Count Graph

Count Marker

96

Aspergillus fully automated rapid detection by Microbio μ3D



Aspergillus fully automated rapid detection by Microbio μ3D, Count Marker



Sabouraud Dextrose Agar (SDA) Media

Count

Count Graph

Count Marker

107

Aspergillus fully aoutomated detection by Microbio μ3D

Aspergillus fully automated detection by Microbio μ3D

Penicillium citrinum Detection

A detection example of Penicillum citrinum grown on PDA is shown below. The detection and enumeration by MicroBio μ3D are completed at 45hr.

Test System

MicroBio µ3D AutoScanner

Species strain

Penicillium citrinum(NBRC 6352)

Agar Media

Potato Dextrose Agar (PDA) Media

Sample

0.1ml spread plate

Incubation

28ºC, 72hr

Detection Result

Detection and colony count are completed within about 45hr.



Potato Dextrose Agar (PDA) Media

Count

Coujnt Graph

Count Marker

220

Penicillium fully aoutomated rapid detection by Microbio μ3D

Penicillium fully automated rapid detection by Microbio μ3D, Count Marker

Candida albicans Detection

A detection example of Candida albicans grown on PDA is shown below. The detection and enumeration by MicroBio μ3D are completed at 20hr.

Test System

MicroBio µ3D AutoScanner

Species strain

Candida albicans(NBRC1594)

Agar Media

Potato Dextrose Agar (PDA) Media

Sample

0.1ml spread plate

Incubation

28ºC, 24hr

Detection Result

Detection and colony count are completed within about 20hr.



Potato Dextrose Agar (PDA) Media

Count

Count Graph and Plate Image

Count Marker

763

カンジダ 全自動 迅速 カビ検出 Microbio μ3D



カンジダ 全自動 迅速 カビ検出 Microbio μ3D
